StarTech.com PEX4S953LP

Native single chip design Includes a full profile and low profile/half-height bracket On chip 256-byte depth FIFO in transmit/receive path of each port Single-Lane (x1) PCI-Express with throughput up to 2.5Gbps Supports hardware and software flow control

4 PORT SERIAL CARD: Serial controller card w/16950 UART based on ASIX AX99100, allows 4x DB9 ports w/bi-directional RS232 speeds up to 921.6Kbps per port, available 256 byte FIFO buffer; Upgraded version of our popular card PEX4S952LP OPTIONAL CONFIGURABLE POWER: PCIe multiport serial card provides 12v, 5v, or none through pin 9 w/up to 2A total; Each of the 4 ports are individually configurable; DB44 to 4x DB9 breakout cable incl STANDARD PROFILE & LOW PROFILE BRACKET: PCI Express RS232 serial adapter card has low profile bracket pre-installed & 1x standard bracket incl for versatile install; Supports Windows XP and up & Linux VERSATILE APPLICATIONS: For low/standard profile desktop/servers w/ uses in point of sale terminals, PLCs, control/automation in factories, scientific sensors, medical equipment, scanner, oscilloscope

PCI Express to Serial Adapter | 921.6Kbps | Windows® and Linux® CompatibleThis PCI Express RS232 serial adapter card lets you add four RS232 (DB9) serial ports to your computer through a PCI Express (PCIe) slot. The 4 port PCIe serial card enables you to interact with serial devices. such as card readers. printers. PIN pads. and modems. at speeds of up to 921.6Kbps.Maximum CompatibilityWith broad OS support. including for Windows and Linux. this PCI E serial card is easy to integrate into mixed environments. The card comes pre-configured with low-profile brackets and includes optional full-profile brackets. so installation is easy regardless of the case form factor. This card is a direct replacement for PEX4S952LP .Experience Optimal Technology• This PCIe to serial adapter supports the following features:• Compatible with industry-standard 16950 UART• Supports max baud rate of up-to 921.6Kbps• Provides 5/12V power output on Pin 9 when external power is connected• 256-byte depth FIFO cache per transmitter and receiver• Supports 9. 8. 7. 6. 5 data bits (one per port)• Asix AX99100 chipsetPCI Express 1.1 compliantThe Choice of IT Pros Since 1985StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to IT Professionals. Our local StarTech.com Technical Advisors have broad product expertise and work directly with our StarTech.com Engineers to provide support for our customers both pre and post-sales.PEX4S03LP is backed by a StarTech.com lifetime warranty and free lifetime technical support.The StarTech.com Advantage

Startech 4-Port Pci Express Rs232 Serial Adapter Card Pcie Serial Db9 Controller, Computers/Tablets & Networking > Computer Components & Parts > Interface/Add-On Cards > Port Expansion Cards

PCI Express to Serial Adapter | 921.6Kbps | Windows and Linux Compatible This PCI Express RS232 serial adapter card lets you add four RS232 (DB9)...

4 Port RS232 Serial Pci-Ex Adaptor Card With 16950 Uart Low Profile Bracket, Computers/Tablets & Networking > Computer Components & Parts > Interface/Add-On Cards > Port Expansion Cards

StarTech.com PCI Express serielle Schnittstellenkarte (4 Ports, 16950 UART, Low, Computers/Tablets & Networking > Computer Components & Parts > Interface/Add-On Cards > Port Expansion Cards
