Aten CE700A

The CE700A is a USB KVM Extender with superior video quality and built-in ESD and surge protection that allows access to a computer system up to 150 meters away from a remote USB console (USB keyboard. monitor. and USB mouse).The CE700A improves on previous designs by: 1) incorporating 8KV/15KV ESD protection and 2KV surge protection; 2) providing superior video quality - up to 1920 x 1200 resolution; 3) using inexpensive Cat 5e cable. instead of bulkier. more expensive. standard cables. for a much neater. more convenient. more reliable data transfer connection; 4) it is able to sense the distance to the system and automatically adjusts the gain accordingly; and 5) it features a custom ASIC to ensure the utmost in reliability and compatibility.

Features: - Cat 5e cable connects the Local and Remote Units - up to 150m apart - Dual console operation - control your system from both the local and remote USB keyboard monitor and mouse consoles - Built-in ASIC for greater reliability and compatibility - Auto Signal Compensation (ASC) - USB Keyboard and USB Mouse Ports - USB overcurrent detection and prevention - Pushbutton operating mode selection (Local Unit only) - select between Local and Auto operating modes. - Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection - Automatic gain control - adjusts signal strength to compensate for distance - High resolution video - up to 1920 x 1200@ 60Hz (30m ); 1600 x 1200@ 60Hz (100m); 1280 x 1024@ 60Hz (150m) - Supports VGA SVGA SXGA UXGA WUXGA and multisyncmonitors; local monitor supports DDC; DDC2; DDC2B - Rack mountableEasy to install - no software required - connecting cables to the devices is all it takes - Multiplatform support - Windows Linux Package Contents - 1x CE700AL USB KVM Extender (Local Unit) - 1x CE700AR USB KVM Extender (Remote Unit) - 2x 0AD6-1605-09EG Power Adapters - 1x USB KVM Cable (1.8m) - 1x Mounting Kit - 1x User Instructions
